forensic science, and veterinary industries.
-has interchangeable pairs of 20x widefield eyepieces, a 2x objective, LED lighting, and a boom-arm stand.
-The binocular viewing head has an interpupillary range of 50 to 77mm and a 30-degree inclination to reduce eye and neck strain.
-It has interchangeable pairs of WF10x18mm and WF20x10mm eyepieces combine with the 1x objective to provide 20x and 40x magnification,
and a longer working distance for inspecting large-scale specimens that require handling or repair.
Eyepiece: 45° tilt, 360° rotating trinocular eyepiece, distance adjustment range: 54~76mm, both eyes can be adjusted with a range of ±5 diopters; trinoculars can be 100% split and trinocular Imaging.
Eyepiece: Use the high-eye wide-angle eyepiece WF10X20 to provide convenience for the wearer of the glasses.
WF15X15mm, WF20X10mm, WF25X9mm, WF30X8mm
Optional: WF15X15mm, WF20X10mm, WF25X9mm, WF30X8mm
Objective lens: 0.7X~4.5X continuous zoom objective lens to ensure image surface coke
Photographic eyepiece: Standard 1.0X; optional 0.45X and 0.35X.
Zoom range: 3.5X~180X, continuous zoom.
It can be used with auxiliary objectives: 0.3X, 0.5X, 0.75X, 1.0X, 2.0X
Working distance: standard working distance is 100mm, with each auxiliary objective lens, the working distance extends from 30mm to 265mm.
Light source system: various types of electric lighting systems, LED lighting and external circular fluorescent lamps, LED lighting
Focusing mechanism: adjustable focus hand wheel is adjustable, lifting range 50mm
Stand: optional plate stand, vertical arm stand, light source stand, rocker stand and universal stand.
SIZE: 52.3*26.9*38.3 CM
G.W: 7 G
