Operating steps:

1.Plug in the power cord then turn on the power switch.

2.Setting time 10 to 15 minute for bubble removing.
3.Setting temperature to the range of 40℃ to 50℃ for bubble removing.
4.Adjusting Pressure Regulating Valve to the range of 5.0kg/cm² to 7.0kg/cm².
5.Opening the door and putting LCD which are finished laminating step into bubble removing area.
6.Closing the door and press the START Button.The machine will start to remove bubble and exhaust automatically according to the setting time.
7.Opening the door and please kindly take out LCD.

Supply：  AC220V/AC110V

Power：   350W

Size：   280*260*320mm
Weight：  16KG
Packing Size：  400*340*380mm
Packing Weight：  19.2KG
